Linux UHD Set-Top-Box
Enjoy relaxing and cozy TV evenings with sharp, top-quality pictures. With the VU+ Duo 4K SE you are using a high-end open-source Linux UHD receiver that enables you to watch both ultra-high-resolution and conventional television. Let yourself be enchanted by films and series with the images of the VU+ Duo 4K SE. The VU+ Duo 4K SE is a digital satellite receiver for UHD and HD TV and radio programs. The heart of the VU+ Duo 4K SE is the 4x 1,500 MHz quad-core processor with ARM architecture. Make TV an experience in Ultra High Definition (UHD) with the VU+ Duo 4K SE set-top box.
​
What is a DVB-S2 FBC Twin Tuner?
​
A DVB-S2 FBC Twin Tuner has eight demodulators. With two standard (e.g. twin LNB) satellite feed lines, the tuner is comparable to two conventional and six additional tuners that work in loop-through mode. This means that you can watch, stream or record channels from eight different transponders from two different satellite levels at the same time. In SCR mode (unicable) with eight frequencies, this corresponds to eight conventional tuners.
​
What is DVB-C FBC Tuner?
​
A DVB-C FBC tuner has eight demodulators. This corresponds to a receiver with eight conventional DVB-C tuners. You can watch, stream or record eight channels at the same time.
Specifications
CPU type
CPU (MHz)
RAM (MB)
Flash (MB)
flash type
DVB
HDTV
3D TV
Pip
Common Interface
Smart card
USB
RS232
LAN (Mbps)
HDD
ATA
eSATA
SCART
HDMI
screen
Other Connectors
ARM
4x1500
3072
4096
eMMC
1x FBC tuner slot
Yes
Yes
Yes
2
1
2x 3.0
Yes
Gigabit LAN
2.5" max height 10.5 mm
SATA III
No
-
1 x HDMI 2.0 in 1 x HDMI 2.0 out
2.4" TFT LCD display mini TV
Digital Audio: S/PDIF
